BTR-82



BTR-82 Armoured vehicle personnel carrier



a
BTR-82 armoured personnel carrier technical data sheet specifications information description pictures photos images intelligence identification intelligence Russia Russian army defence industry military technology Arzamas Engineering Plant

Description
The BTR-82 is an upgraded version of the BTR-80 wheeled armored vehicles. In December 2008, Russia's Military Industrial Company (MIC) was already testing the prototypes which were unveiled in December 2009. In April 2010, Russian defence industry has started to market the BTR-82 and BTR-82A as a modernization program for existing BTR-80 operators. The BTR-82 was purchased by the armed forces of Kazakhstan.

Variants
- BTR-82: basic version with 14.5 mm machine gun
- BTR-82A: armed with one 2A72 30mm cannon

Technical Data
Back to top
Armament
The firepower of the BTR-82 is increased by the use of a new unified fighting module with an electric drive armed with one 14.5 mm machine gun coupled with a 7.62 mm machine gun. The turret is fully stabilized on the two axes and fitted with new sights. The ammunition feed system of the KPVT 7.62 mm machine gun uses a single band of 2,000 cartridges and 500 rounds for the 14.5mm machine gun. The BTR-82 can fire on the move in day and night operations.
Design and protection
The layout of the BTR-82 is very similar to the BTR-80. The BTR-82 is more protected than the basic version of BTR-80. The vehicle is fitted with a reinforced multi-layer floor which provides protection against mines and improvised explosive devices (IEDs). The BTR-82 is also equipped with new seats and a special suspension that have energy-absorbing properties which increase the protection for the personnel inside the vehicle against mine blast. The hull of the BTR-82 is made with new armored vehicle ballistic protection of laminated synthetic material such as Kevlar.
Propulsion
The BTR-82 wheeled armored vehicle personnel carrier features energy absorbing structures and a new powerful Diesel engine KAMAZ 740.14-300 developing 300 hp of power. The BTR-82 is also fitted with new transmission components and suspension allowing an increased average speed in rough terrain. The BTR-82 can run at a maximum speed of 80 km/h on road with a maximum range of 600 km.
Accessories
The gunner gets a new stabilized day/night fire control system TKN-4GA. The vehicle command system is equipped with advanced communications, topographic maps and a surveillance camera (TKN-AI) for the vehicle's commander. TKN-AI is fitted with a laser range finder which allows the commander of the vehicle to detect the enemy target at a distance of 3 km. The BTR-82 is also equipped with an improved fire extinguishing system that improves safety in case of fire and explosion. To increase the comfort of the crew, the BTR-82 is equipped with an air-conditioning system, which also serves to optimize the operations conditions of electronic devices of the vehicle. The BTR-82 is equipped with new radio station R-168-25-U2, topographic orientation system, "Trona-1" with independent satellite channels and receiver navigation data. The Trona-1 positioning system is designed to enhance the accuracy and credibility of navigation data by the integration of the vehicle's navigation system with the receiver of the GLONASS and NAVSTAR satellite navigation systems.

Specifications
Back to top
Armament
One 14.5 mm machine gun and one coaxial 7.62 mm machine gun.
Country users
Russia, Kazakhstan
Designer Country
Russia
Accessories
Fire control system TKN-4GA, surveillance camera TKN-AI, air-conditioning. Trona-1 positioning system.
Crew
3 + 7 soldiers
Armor
Protection against small arms ans shell splinters, multi-layer floor increase protection against IED's.
Weight
? kg
Speed
80 km/h maximum road speed
Range
600 km
a
a

Dimensions
Length, ? m; Width, ? m; Height, ? m
