MUSKETEER Saymar LTD Multirole light armoured vehicle





General Information

Technical Data

Details View

Pictures




General information
The MUSKETEER is a Multirole Light Armored Vehicle (MLAV) designed to perform extensive range of military and law enforcement tasks. The vehicle can be configured for a wide variety of missions for military, homeland security, law enforcement and urban operation. The MUSKETEER is presented for the first time at the Worldwide exhibition of internal State security, Milipol 2009. The Musketeer is based on the reliable heavy duty legendary Toyota LandCruiser vehicle, the Musketeer guarantees the ease of maintenance and ensure low life cycle cost.
Variants :
No variant

Technical data

Armament
The Musketter can be fitted with a remote controlled weapon station armed with weapons up to 12,7 mm calibre.
Protection
The MUSKETEER is constructed of a detachable armored body, providing passengers with NATO B6 (STANAG 4569 level 1) ballistic protection. This can be upgraded to B7 protection level if requested by a customer. The hull is protected all around NATO level B6 (STANAG 4569 Level 1), including engine compartment. The main passenger compartment provides NATO Level B6 (Stanag 4569). Florr and fuel tanks are protected against hand grenade blast. The Musketeer can be fitted with an optional add-on armour, to obtain a level of protection Level 3 STANAG 4569.
Propulsion
The Musketeer can be motorised with a 4.2L 6 cylinder OHC Diesel Engine or 4.2 L 6 Cylinder Turbo_Charged Diesel engine coupled to a 5 speed manual gear box, with HI / LOW range transfer box.
Accessories
Standard equipment of Musketeer is composed with rear observation camera, air conditioning system, and large cargo compartment. Wheels are fitted with run-flat inserts system to provide 50 km additional driving capbility while tiers are punctured. In option the Musketeer can be fitted with remote controlled searchlight, flashing beacon, winch, mesh windows protection, various weapons mounts, and navigation system.

Specifications

Armament
One 7,62 or 12,7 mm machine gun.
a
Country users
Prototype
Designer Company
Saymar LTD.
Accessories
Run-flat system
Crew
4 - 5 soldiers
Armor
Basic Protection Level 1 Stanag 4569
Weight
4,000 kg
Speed
?
Range
?
Dimensions
Lenght, 5,08 m; Width, 1,85 m; Height, 1,995 m
